Referencing parts and specifications for noise monitoring terminals
Who is this article for?
Users who need to reference parts and specifications.
No special access or permissions are required.
This article provides a comprehensive parts list and technical specifications for noise monitoring terminal (NMT) components, including EU declarations of conformity and disposal information.
Understanding the parts list
The following tables detail all available components for fixed and mobile noise monitoring stations, including part numbers and specific applications.
Masts and mounting equipment
|
Part |
Part number |
Comment |
|
Microphone mast 6m fixed |
MST-FIXED-6M |
For fixed stations |
|
Microphone mast 3m movable ballasted |
MST-MVBLE-3M |
For fixed stations |
|
Microphone mast 2m mobile |
MST-MBILE-2M |
For mobile stations |
|
Mast padlock |
MST-ARSPADLOCK |
For tiltable masts |
|
Pole adapter for B&K mast |
ADP-BK2CASPER |
For existing masts previously equipped with B&K microphone |
|
Pole adapter for new masts |
ADP-GEN42MM2CASPER |
For fixed stations masts |
|
Pole adapter for mobile mast |
ADP-GEN35MM2CASPER-BK |
Black |
|
Anti-climb gear |
MST-ANTICLIMB-42MM |
For masts where needed |
Microphones and adapters
|
Part |
Part number |
Comment |
|
Microphone adapter for NTi WP30 |
ADP-CASPER2NTIWP30 |
For NTi WP30 |
|
Measurement microphone M2340 |
NTi 600040230 |
For NTi XL2, protected by NTi WP30 |
|
Weather protection WP30 |
NTi 600040060 |
For NTi M2340 |
|
NTi wind screen (2 pieces) |
NTi 600040061 |
For NTi WP30 |
|
NTi replacement mesh and O-rings (5 pieces) |
NTi 600040065 |
For NTi WP30 |
Cabinets and cases
|
Part |
Part number |
Comment |
|
Cabinet for fixed stations |
CBT-AE1007600-WALL |
NMT components included except microphone, microphone cable, microphone protection |
|
Cabinet for fixed stations |
CBT-AE1007600-POLE |
NMT components included except microphone, microphone cable, microphone protection |
|
Mobile station main case |
ARS-XL2-MOBILE |
Main case fully equipped with its contents |
|
Mobile station battery case |
ARS-BatteryCase |
Battery case fully equipped with its contents |
Identifying sound level meters and accessories
|
Part |
Part number |
Comment |
|
NTi sound level meter XL2-TA |
NTi 600000330+600000377+600000375 |
With RMO option |
|
NTi sound level meter XL2 power supply |
CBL-XL2PWR |
Custom power cable |
|
NTi SD card for XL2 |
NTi 600000374 |
For NTi XL2 |
|
NTi USB cable for XL2 |
CBL-XL2USB |
For NTi XL2 |
|
Sound level calibrator CAL1 |
NTi 600000388 |
94dB-114dB Class 1 |
Selecting microphone cables
Different cable lengths and specifications are available for fixed and mobile stations.
Fixed station cables
|
Part |
Part number |
Comment |
|
NTi microphone cable ASD5 5m length |
NTi 600000336 |
For fixed stations |
|
NTi microphone cable ASD10 10m length |
NTi 600000364 |
For fixed stations |
|
NTi microphone cable ASD20 20m length |
NTi 600000365 |
For fixed stations |
Mobile station cables
|
Part |
Part number |
Comment |
|
NTi microphone cable ASD5 IP65 |
NTi 600000098 |
For mobile stations |
|
NTi microphone cable ASD10 IP65 |
NTi 600000362 |
For mobile stations |
|
NTi microphone cable ASD20 IP65 |
NTi 600000360 |
For mobile stations |
|
NTi microphone cable inside mobile case |
NTi 600000092 |
For mobile stations |
Locating data management components
|
Part |
Part number |
Comment |
|
NMT Manager - Strato-Pi Nano computer |
CPT-STRATOPI |
Data collector |
|
8GB micro SD card for NMT Manager OS |
MSD-NMTOS |
Pre-formatted and pre-configured |
|
64GB USB stick (thumb drive) for NMT Manager data storage |
USB-NMTDATA-64GB |
F2FS pre-formatted |
|
USB audio adapter |
USB-AUDIOMANH |
Consists of an assembly of a USB audio adapter and USB extension cable |
|
Audio cable |
CBL-XL2AUDIO |
Consists of an assembly of two custom audio cables between XL2 output and audio adapter input, with noise filter |
Finding modem and antenna components
|
Part |
Part number |
Comment |
|
Modem TRB140 |
MDM-TRB140-EU |
With custom power cable |
|
Modem antenna for fixed station |
ANT-MODEM-FIXED |
Puck antenna |
|
Modem antenna for mobile station |
ANT-MODEM-MBILE |
Magnetic base 2G, 3G and 4G antenna 3m CELF200 SMA Male |
Identifying power and electrical components
|
Part |
Part number |
Comment |
|
Ideagen power control box |
PCB-V2.4 |
Smart power management |
|
Circuit breaker |
SCHNEIDER R9D01606 |
230V 6A 30mA 6kA - IEC61009-1 |
|
Surge protection device (SPD) |
DEHN DR M 2P 255 (953 200) |
Type 3 - Class III - IEC61643-11 |
|
AC/DC adapter |
PWR-ACDCMW-15V |
DIN Rail Power Supply (PSU), ITE, 1 Output, 60 W, 15 V, 4 A |
|
Battery for fixed station |
AGM BAT212200084 |
12V battery 22Ah |
|
Battery for mobile station |
GEL BAT412550104 |
12V gel battery 60Ah |
|
Power supply cable for mobile on battery |
CBL-MBILE-PWRBATT |
For mobile stations |
|
Power supply cable for mobile on mains |
CBL-MBILE-PWRMAINS |
For mobile stations |
|
Charger for mobile station battery case |
CHG-MBILE-BATT |
For mobile stations |
|
Fuse 3.15A |
Standard part |
Glass fuse |
|
Fuse 10A |
Standard part |
Car fuse |
|
Fuse 1A |
Standard part |
Glass fuse |
Locating weather and aircraft tracking equipment
|
Part |
Part number |
Comment |
|
Weather station GMX600 |
WST-GMX600 |
Gill Maximet GMX600 with custom cables and custom arm |
|
ADS-B receiver |
PRO STICK PLUS |
|
|
Antenna for ADS-B receiver |
ANT-ADSB-60CM |
60cm 1090MHz antenna |
|
Cable for ADS-B receiver |
CBL-ADSB-5M |
SMA Male to N-Type Male antenna cable - 5m |
Finding connecting cables and accessories
|
Part |
Part number |
Comment |
|
Set of connecting cables between components |
Specific |
For fixed stations |
|
Set of connecting cables between components |
Specific |
For mobile stations |
Reviewing mobile NMT declaration of conformity
The mobile noise monitoring terminal complies with European Union directives and standards.
EU Declaration of Conformity
Document Reference: 2022-DC-ARS-XL2-MOBILE
CASPER B.V., Parklaan 32, 2011KW Haarlem, The Netherlands, declares under sole responsibility that the product complies with the following requirements:
|
Compliance |
2014/35/EU Low voltage Directive |
|
Standards applied |
Safety: EN 61010-1:2010 + A1:2019 |
The product must be used in the manner for which it is intended and in accordance with the manufacturer's specifications and instructions.
|
Year of CE mark apposition: 2022 |
Signed for and on behalf of CASPER B.V.
Heleen Erkamp |
Reviewing fixed NMT declaration of conformity
The fixed noise monitoring terminal complies with European Union directives and standards.
EU Declaration of Conformity
Document Reference: 2022-DC-ARS-XL2-FIXED
CASPER B.V., Parklaan 32, 2011KW Haarlem, The Netherlands, declares under sole responsibility that the product complies with the following requirements:
|
Compliance |
2014/35/EU Low voltage Directive |
|
Standards applied |
Safety: EN 61010-1:2010 + A1:2019 |
The product must be used in the manner for which it is intended and in accordance with the manufacturer's specifications and instructions.
|
Year of CE mark apposition: 2022 |
Signed for and on behalf of CASPER B.V.
Heleen Erkamp |
Disposing of equipment and recycling
Proper disposal of electrical equipment and batteries is required in accordance with local regulations.
Waste Electrical and Electronic Equipment
|
This marking on the product, accessories or literature indicates that the product must not be disposed of in household garbage at the end of its service life. Applicable in the European Union and other European countries with separate collection systems. At the end of its service life, bring the product to a collecting point for electrical recycling in accordance with local legal regulations. |
|
Dispose of used batteries according to local regulations and the battery manufacturer's instructions. |
Cet article fournit une liste complète des pièces, numéros de référence et spécifications pour les systèmes de surveillance du bruit NMT fixes et mobiles.
Comprendre la liste de pièces
La liste de pièces contient tous les composants nécessaires pour les stations de surveillance du bruit fixes et mobiles. Chaque pièce est identifiée par un numéro de référence unique et comprend des commentaires sur son utilisation spécifique.
Identifier les sonomètres et accessoires
Les composants principaux de mesure du bruit comprennent :
- NTi SOUND LEVEL METER XL2-TA (NTi 600000330+600000377+600000375) avec option RMO
- NTi SOUND LEVEL METER XL2 POWER SUPPLY (CBL-XL2PWR) câble d'alimentation personnalisé
- NTi SD CARD FOR XL2 (NTi 600000374)
- NTi USB CABLE FOR XL2 (CBL-XL2USB)
- MEASUREMENT MICROPHONE M2340 (NTi 600040230) pour NTi XL2, protégé par NTi WP30
- WEATHER PROTECTION WP30 (NTi 600040060) pour NTi M2340
- NTi WIND SCREEN (2 PCS) (NTi 600040061) pour NTi WP30
- NTi REPLACEMENT MESH / O-RINGS (5 PCS) (NTi 600040065) pour NTi WP30
- SOUND LEVEL CALIBRATOR CAL1 (NTi 600000388) 94DB-114DB CLASS1
Les mâts de microphone disponibles incluent :
- MICROPHONE MAST 6M FIXED (MST-FIXED-6M) pour stations fixes
- MICROPHONE MAST 3M MOVABLE BALLASTED (MST-MVBLE-3M) pour stations fixes, comprend un support au sol
- MICROPHONE MAST 2M MOBILE (MST-MBILE-2M) pour stations mobiles
- MAST PADLOCK (MST-ARSPADLOCK) pour mâts inclinables
- Anti-climb gear (MST-ANTICLIMB-42MM) pour mâts si nécessaire
Les adaptateurs de mât comprennent :
- POLE ADAPTER FOR B&K MAST (ADP-BK2CASPER) pour mâts existants précédemment équipés de microphone B&K
- POLE ADAPTER FOR NEW MASTS (ADP-GEN42MM2CASPER) pour mâts de stations fixes
- POLE ADAPTER FOR MOBILE MAST (ADP-GEN35MM2CASPER-BK) noir
- MICROPHONE ADAPTER FOR NTi WP30 (ADP-CASPER2NTIWP30)
Sélectionner les câbles de microphone
Pour les stations fixes, utilisez :
- NTi MICROPHONE CABLE ASD5 5M LENGTH (NTi 600000336)
- NTi MICROPHONE CABLE ASD10 10M LENGTH (NTi 600000364)
- NTi MICROPHONE CABLE ASD20 20M LENGTH (NTi 600000365)
Pour les stations mobiles, utilisez :
- NTi MICROPHONE CABLE ASD5 IP65 (NTi 600000098)
- NTi MICROPHONE CABLE ASD10 IP65 (NTi 600000362)
- NTi MICROPHONE CABLE ASD20 IP65 (NTi 600000360)
- NTi MICROPHONE CABLE INSIDE MOBILE CASE (NTi 600000092)
Localiser les composants de gestion des données
Les composants de collecte et de stockage des données comprennent :
- NMT MANAGER - STRATO-PI NANO COMPUTER (CPT-STRATOPI) collecteur de données avec câble d'alimentation personnalisé et câble de communication
- 8GB MICRO SD CARD FOR NMT MANAGER OS (MSD-NMTOS) pré-formatée et pré-configurée
- 64GB USB STICK (THUMB DRIVE) FOR NMT MANAGER DATA STORAGE (USB-NMTDATA-64GB) formatée F2FS
- USB AUDIO ADAPTER (USB-AUDIOMANH) composé d'un adaptateur audio USB et d'un câble d'extension USB
- AUDIO CABLE (CBL-XL2AUDIO) composé d'un assemblage de 2 câbles audio personnalisés entre la sortie XL2 et l'entrée de l'adaptateur audio, avec filtre anti-bruit
Trouver les composants modem et antenne
Les composants de communication comprennent :
- MODEM TRB140 (MDM-TRB140-EU) avec câble d'alimentation personnalisé, comprend un câble de communication USB
- MODEM ANTENNA FOR FIXED STATION (ANT-MODEM-FIXED) antenne puck
- MODEM ANTENNA FOR MOBILE STATION (ANT-MODEM-MBILE) antenne à base magnétique 2G, 3G et 4G 3m CELF200 SMAMale
Identifier les composants d'alimentation et électriques
Les composants de gestion de l'alimentation comprennent :
- CASPER POWER CONTROL BOX (PCB-V2.4) gestion intelligente de l'alimentation
- CIRCUIT BREAKER (SCHNEIDER R9D01606) 230V 6A 30MA 6KA - IEC61009-1
- SURGE PROTECTION DEVICE (SPD) (DEHN DR M 2P 255 (953 200)) TYPE 3 - CLASS III - IEC61643-11
- AC/DC ADAPTER (PWR-ACDCMW-15V) alimentation sur rail DIN (PSU), ITE, 1 sortie, 60 W, 15 V, 4 A
Les batteries disponibles incluent :
- BATTERY FOR FIXED STATION (AGM BAT212200084) batterie 12V 22AH
- BATTERY FOR MOBILE STATION (GEL BAT412550104) batterie GEL 12V 60AH, durée de conservation augmentée avec stockage à température fraîche
Les câbles d'alimentation pour stations mobiles comprennent :
- POWER SUPPLY CABLE FOR MOBILE ON BATTERY (CBL-MBILE-PWRBATT)
- POWER SUPPLY CABLE FOR MOBILE ON MAINS (CBL-MBILE-PWRMAINS)
- CHARGER FOR MOBILE STATION BATTERY CASE (CHG-MBILE-BATT)
Les fusibles nécessaires incluent :
- FUSE 3.15A (pièce standard) fusible en verre pour stations fixes et mobiles
- FUSE 10A (pièce standard) fusible automobile pour stations mobiles
- FUSE 1A (pièce standard) fusible en verre pour stations mobiles
Localiser les équipements météorologiques et de suivi d'aéronefs
Les composants de surveillance environnementale comprennent :
- WEATHER STATION GMX600 (WST-GMX600) Gill Maximet GMX600 avec câbles personnalisés et bras personnalisé
- ADS B RECEIVER (PRO STICK PLUS)
- ANTENNA FOR ADS B RECEIVER (ANT-ADSB-60CM) antenne 1090MHz 60cm
- CABLE FOR ADS-B RECEIVER (CBL-ADSB-5M) câble d'antenne SMA Male vers N-Type Male - 5M
Trouver les câbles de connexion et accessoires
Les ensembles de câbles de connexion entre composants sont disponibles :
- SET OF CONNECTING CABLES BETWEEN COMPONENTS (spécifique) pour stations fixes
- SET OF CONNECTING CABLES BETWEEN COMPONENTS (spécifique) pour stations mobiles
Les boîtiers de station comprennent :
- CABINET FOR FIXED STATIONS (CBT-AE1007600-WALL) composants NMT inclus sauf microphone, câble de microphone, protection de microphone
- CABINET FOR FIXED STATIONS (CBT-AE1007600-POLE) composants NMT inclus sauf microphone, câble de microphone, protection de microphone
- MOBILE STATION MAIN CASE (ARS-XL2-MOBILE) boîtier principal entièrement équipé avec son contenu
- MOBILE STATION BATTERY CASE (ARS-BatteryCase) boîtier de batterie entièrement équipé avec son contenu
Consulter la déclaration de conformité NMT mobile
La déclaration de conformité UE pour le système NMT mobile (référence du document : 2022-DC-ARS-XL2-MOBILE) est émise par CASPER B.V., Parklaan 32, 2011KW Haarlem, Pays-Bas.
Le produit est conforme aux exigences des directives européennes suivantes :
- 2014/35/EU Low voltage Directive
- 2014/30/EU Electromagnetic compatibility
Les normes suivantes ont été appliquées pour évaluer la conformité :
- Sécurité : EN 61010-1:2010 + A1:2019
- CEM : EN 61326-1 : 2013, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Une condition est qu'il soit utilisé de la manière pour laquelle il est destiné et conformément aux spécifications et instructions du fabricant.
Année d'apposition du marquage CE : 2022
Signé pour et au nom de CASPER B.V. par Heleen Erkamp, Chief Executive Officer, Haarlem, 24 octobre 2022.
Consulter la déclaration de conformité NMT fixe
La déclaration de conformité UE pour le système NMT fixe (référence du document : 2022-DC-ARS-XL2-FIXED) est émise par CASPER B.V., Parklaan 32, 2011KW Haarlem, Pays-Bas.
Le produit est conforme aux exigences des directives européennes suivantes :
- 2014/35/EU Low voltage Directive
- 2014/30/EU Electromagnetic compatibility
Les normes suivantes ont été appliquées pour évaluer la conformité :
- Sécurité : EN 61010-1:2010 + A1:2019
- CEM : EN 61326-1 : 2013, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
Une condition est qu'il soit utilisé de la manière pour laquelle il est destiné et conformément aux spécifications et instructions du fabricant.
Année d'apposition du marquage CE : 2022
Signé pour et au nom de CASPER B.V. par Heleen Erkamp, Chief Executive Officer, Haarlem, 24 octobre 2022.
Mettre au rebut l'équipement et recycler
Les déchets d'équipements électriques et électroniques (applicable dans l'Union européenne et dans d'autres pays européens dotés de systèmes de collecte sélective) ne doivent pas être jetés dans les ordures ménagères à la fin de leur durée de vie.
Ce marquage sur le produit, les accessoires ou la documentation indique que le produit doit être apporté à un point de collecte pour le recyclage électrique conformément aux dispositions légales locales à la fin de sa durée de vie.
Note : Les batteries usagées doivent être mises au rebut conformément aux réglementations locales et aux instructions du fabricant de la pile.
This article provides comprehensive parts lists, technical specifications, and compliance documentation for NMT (Noise Monitoring Terminal) systems, including both fixed and mobile station configurations.
Understanding the parts list
The NMT system comprises various components organised by function and station type. Each part has a unique part number for ordering and identification purposes.
Note: Parts marked as Standard part are commercially available components that can be sourced from multiple suppliers.
Identifying sound level meters and accessories
The following components form the core measurement system:
- NTi SOUND LEVEL METER XL2-TA (NTi 600000330+600000377+600000375) – includes RMO option
- NTi SOUND LEVEL METER XL2 POWER SUPPLY (CBL-XL2PWR) – custom power cable
- NTi SD CARD FOR XL2 (NTi 600000374)
- NTi USB CABLE FOR XL2 (CBL-XL2USB)
- MEASUREMENT MICROPHONE M2340 (NTi 600040230) – protected by NTi WP30
- WEATHER PROTECTION WP30 (NTi 600040060) – for NTi M2340
- NTi WIND SCREEN (2 PCS) (NTi 600040061) – for NTi WP30
- NTi REPLACEMENT MESH / O-RINGS (5 PCS) (NTi 600040065) – for NTi WP30
- SOUND LEVEL CALIBRATOR CAL1 (NTi 600000388) – 94DB-114DB CLASS1
The system includes adapters for different microphone configurations:
- MICROPHONE ADAPTER FOR NTi WP30 (ADP-CASPER2NTIWP30)
- POLE ADAPTER FOR B&K MAST (ADP-BK2CASPER) – for existing masts previously equipped with B&K microphones
- POLE ADAPTER FOR NEW MASTS (ADP-GEN42MM2CASPER) – for fixed station masts
- POLE ADAPTER FOR MOBILE MAST (ADP-GEN35MM2CASPER-BK) – black finish
Selecting microphone cables
Different cable types are available depending on station type and installation requirements.
Fixed station cables:
- NTi MICROPHONE CABLE ASD5 5M LENGTH (NTi 600000336)
- NTi MICROPHONE CABLE ASD10 10M LENGTH (NTi 600000364)
- NTi MICROPHONE CABLE ASD20 20M LENGTH (NTi 600000365)
Mobile station cables (IP65 rated):
- NTi MICROPHONE CABLE ASD5 IP65 (NTi 600000098)
- NTi MICROPHONE CABLE ASD10 IP65 (NTi 600000362)
- NTi MICROPHONE CABLE ASD20 IP65 (NTi 600000360)
- NTi MICROPHONE CABLE INSIDE MOBILE CASE (NTi 600000092)
Locating data management components
The NMT Manager system handles data collection and storage:
- NMT MANAGER - STRATO-PI NANO COMPUTER (CPT-STRATOPI) – data collector with custom power cable and communication cable
- 8GB MICRO SD CARD FOR NMT MANAGER OS (MSD-NMTOS) – pre-formatted and pre-configured
- 64GB USB STICK (THUMB DRIVE) FOR NMT MANAGER DATA STORAGE (USB-NMTDATA-64GB) – F2FS pre-formatted
- USB AUDIO ADAPTER (USB-AUDIOMANH) – assembly of USB audio adapter and USB extension cable
- AUDIO CABLE (CBL-XL2AUDIO) – assembly of two custom audio cables between XL2 output and audio adapter input, with noise filter
Finding modem and antenna components
Communication components enable remote data transmission:
- MODEM TRB140 (MDM-TRB140-EU) – includes custom power cable and USB communication cable
- MODEM ANTENNA FOR FIXED STATION (ANT-MODEM-FIXED) – puck antenna
- MODEM ANTENNA FOR MOBILE STATION (ANT-MODEM-MBILE) – magnetic base 2G, 3G and 4G antenna 3m CELF200 SMAMale
Identifying power and electrical components
The power management system includes safety and distribution components:
- CASPER POWER CONTROL BOX (PCB-V2.4) – smart power management
- CIRCUIT BREAKER (SCHNEIDER R9D01606) – 230V 6A 30MA 6KA - IEC61009-1
- SURGE PROTECTION DEVICE (SPD) (DEHN DR M 2P 255 (953 200)) – TYPE 3 - CLASS III - IEC61643-11
- AC/DC ADAPTER (PWR-ACDCMW-15V) – DIN Rail Power Supply (PSU), ITE, 1 Output, 60 W, 15 V, 4 A
Batteries:
- BATTERY FOR FIXED STATION (AGM BAT212200084) – 12V battery 22AH
- BATTERY FOR MOBILE STATION (GEL BAT412550104) – 12V GEL battery 60AH (shelf life increased with storage at cool temperature)
- CHARGER FOR MOBILE STATION BATTERY CASE (CHG-MBILE-BATT)
Power cables:
- POWER SUPPLY CABLE FOR MOBILE ON BATTERY (CBL-MBILE-PWRBATT)
- POWER SUPPLY CABLE FOR MOBILE ON MAINS (CBL-MBILE-PWRMAINS)
Fuses:
- FUSE 3.15A – glass fuse for fixed and mobile stations
- FUSE 10A – car fuse for mobile stations
- FUSE 1A – glass fuse for mobile stations
Locating weather and aircraft tracking equipment
Environmental monitoring and aircraft detection components:
- WEATHER STATION GMX600 (WST-GMX600) – Gill Maximet GMX600 with custom cables and custom arm
- ADS B RECEIVER (PRO STICK PLUS)
- ANTENNA FOR ADS B RECEIVER (ANT-ADSB-60CM) – 60cm 1090MHz antenna
- CABLE FOR ADS-B RECEIVER (CBL-ADSB-5M) – SMA Male to N-Type Male antenna cable - 5M
Finding connecting cables and accessories
Station-specific cable sets and mounting hardware:
- SET OF CONNECTING CABLES BETWEEN COMPONENTS (Specific) – for fixed stations
- SET OF CONNECTING CABLES BETWEEN COMPONENTS (specific) – for mobile stations
Mast components:
- MICROPHONE MAST 6M FIXED (MST-FIXED-6M) – for fixed stations
- MICROPHONE MAST 3M MOVABLE BALLASTED (MST-MVBLE-3M) – for fixed stations, includes ground support
- MICROPHONE MAST 2M MOBILE (MST-MBILE-2M) – for mobile stations
- MAST PADLOCK (MST-ARSPADLOCK) – for tiltable masts
- Anti-climb gear (MST-ANTICLIMB-42MM) – for masts where needed
Enclosures:
- CABINET FOR FIXED STATIONS (CBT-AE1007600-WALL) – NMT components included except microphone, microphone cable, microphone protection
- CABINET FOR FIXED STATIONS (CBT-AE1007600-POLE) – NMT components included except microphone, microphone cable, microphone protection
- MOBILE STATION MAIN CASE (ARS-XL2-MOBILE) – main case fully equipped with its contents
- MOBILE STATION BATTERY CASE (ARS-BatteryCase) – battery case fully equipped with its contents
Reviewing mobile NMT declaration of conformity
Document Reference: 2022-DC-ARS-XL2-MOBILE
CASPER B.V., Parklaan 32, 2011KW Haarlem, The Netherlands, declares under sole responsibility that the mobile NMT product complies with the following European directives:
- 2014/35/EU Low voltage Directive
- 2014/30/EU Electromagnetic compatibility
Applied standards:
- Safety: EN 61010-1:2010 + A1:2019
- EMC: EN 61326-1:2013, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
The product must be used in the manner for which it is intended and in accordance with the manufacturer's specifications and instructions.
Year of CE mark apposition: 2022
Signed for and on behalf of CASPER B.V. by Heleen Erkamp, Chief Executive Officer, Haarlem, October 24th, 2022.
Reviewing fixed NMT declaration of conformity
Document Reference: 2022-DC-ARS-XL2-FIXED
CASPER B.V., Parklaan 32, 2011KW Haarlem, The Netherlands, declares under sole responsibility that the fixed NMT product complies with the following European directives:
- 2014/35/EU Low voltage Directive
- 2014/30/EU Electromagnetic compatibility
Applied standards:
- Safety: EN 61010-1:2010 + A1:2019
- EMC: EN 61326-1:2013, EN 55011, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11
The product must be used in the manner for which it is intended and in accordance with the manufacturer's specifications and instructions.
Year of CE mark apposition: 2022
Signed for and on behalf of CASPER B.V. by Heleen Erkamp, Chief Executive Officer, Haarlem, October 24th, 2022.
Disposing of equipment and recycling
Waste electrical and electronic equipment (applicable in the European Union and other European countries with separate collection systems).
The marking on the product, accessories or literature indicates that the product must not be disposed of with household waste at the end of its life. Bring the product to an electrical recycling collection point at the end of its life in accordance with local legal requirements.
Important: Dispose of used batteries according to local regulations and the battery manufacturer's instructions.
